linseed oil plant
AGICO GROUP is committed to providing solutions for the linseed oil mill. We can provide different production capacity requirements or different types of oil mill plants.
- Capacity: 1-50 tpd (customization)
- Technology: cold press, hot press and oil extraction
linseed oil plant for sale
With 20 years improvement, AGICO has become one of the top manufacturers and suppliers of oil extraction machine in China. And become a large-scale modern enterprise integrating R&D, design, production, sales, after-sales service and trade. The extraction techniques of linseed oil include hot pressing, cold pressing and oil extraction.
Linseed oil, extracted from linseed and rich in α-linolenic acid, has the functions of regulating blood lipids, anti-inflammation, improving skin and brain functions, etc. China is one of the major production areas of linseed in the world. The annual output achieved 340,000 tons, accounting for 11.08% of the global total output.
Core linseed Oil plant Machine
clean sieve
magnetic separator
crushing machine
flaking machine
cooking machine
pressing machine
linseed oil plant process
Method 1: Cold press
Linseed has been harvested and sorted. Then clean it and remove impurities. And remove the shell and crush the seed. After being roasted, the linseeds are sent to the pressing stage, from which linseed oil is obtained. Linseed oil undergoes coarse filtration and fine filtration to remove the impurities and colloids therein. Then, further refine by washing, dehydration, and decolorization steps. Finally, hot-pressed linseed oil was obtained.
ADVANTAGES
- Cold pressing make linseed the majority of nutrients in linseed to be well preserved. The product has a refreshing and not greasy taste, and it is rich in polyunsaturated fatty acids.
DISADVANTAGES
- Compard with the oil extraction method, cold press oil yield is rather low. So production cost is higher.
ADVANTAGES
- Hot press produce linseed oil is rich and full-bodied, with a strong aroma and oil yield is rather high.
DISADVANTAGES
- During the high-temperature roasting process of seeds, it is inevitable that certain effective components in the oil will be reduced, and at the same time, the proteins may also undergo denaturation. Thereby influence nutritional value and taste of the product.
Method 2: Hot press
Linseed is collected and screened, then processed to remove impurities, hull, and crushed, after which linseed oil is obtained through low-temperature pressing. After the oil undergoes coarse filtration and fine filtration, the oil carries out low-temperature crystallization for seed maturation and low-temperature filtration, and finally obtains cold-pressed linseed oil.
Method 3: Oil extraction
The extraction method of linseed oil uses using solvent to soak the linseed raw materials, then extracts the oil at high temperatures. The first extracted oil is a mixture of an organic solvent and oil. This oil doesn’t directly eat. It can only be eaten after undergoing a series of chemical treatments such as dewaxing, degumming, dehydration, deodorization, deacidification, and decolorization. After extraction, the color of the oil usually becomes shallower. The seeds still retain a faint trace of the original natural scent.
ADVANTAGES
- The extraction process could extract almost all of the oil from linseed. The economic efficiency is high.
DISADVANTAGES
- The oil extraction method of the linseed oil includes the destruction of nutrients, possible residual chemical solvents, and high oil yield but low quality.
cold press vs hot press
| Item | Cold press | Hot press |
|---|---|---|
| Oil yield | Below 60 ℃ | 130-180℃ |
| Oil extraction temperature | 30%-35% | 40%-45% |
| α-linolenic acid content | ≥55% | ≤45% |
| Price | High | Low |
| Storage condition | Cold storage | Normal temperature |
Advantages of linseed oil factory
Wide applicaton
Our full automatic linseed oil production line not only can extract linseed oil, but also used in other oilseed processing, such as rapeseed, sesame, etc. This wide application makes you expand your product range and meet different market demands.
Customized linseed oil production line
The oil production line of AGICO has advanced technology, which can be customized according to the concrete requirements of different customers. Low failure rate, the normal continuous operating time of the equipment gets full assurance. Long service life, could provide a bigger economic efficiency and production ability for customers.
High efficiency and high output
Our advanced linseed oil press machine could produce oil with 1-50tpd, maximizing the extraction efficiency and yield of the oil. We have optimized the pressing process to ensure full extraction of oil from linseed. It reduces waste and enhances the overall production efficiency.
linseed oil plant price
The price of a flaxseed oil processing line is influenced by capacity, level of automation, refining degree, material of construction (carbon steel or stainless steel), etc. Below is only a rough reference range:
|
Capacity |
Details |
Cost |
|---|---|---|
|
5-15tpd(small-sacle oil mill) |
single or 2 sets of screw oil presses, simple refining, and basic filling |
$15,000–$40,000 |
|
15-30tpd(medium-sacle oil milll) |
complete cleaning, cooking, multiple presses, and a standard refining section. |
$40,000–$120,000 |
|
30-50tpd(large-scale oil mill) |
multiple oil presses in parallel, improved automation, and better energy-saving configuration. |
$120,000–$250,000+ |
leading linseed oil plant manufacturer
Design
Manufacturing
Installation
Debugging
After-sale service
AGICO is a manufacturer of equipment for refining and processing linseed oil, working on research and development of linseed oil production equipment. We have rich experience in the production design of linseed oil equipment. Manufacturing linseed oil equipment is sold to 60+ countries around the world. Our company’s main products are linseed oil pressing equipment, linseed oil refining equipment, linseed oil processing equipment, and linseed oil production equipment.
what we can make seeds and nuts
